Single-lever basin mixer 1/2" XL-Size
Model: 23971003
Eurosmart 2021
Dimensional Drawing
Technical Details
Product Description
for free-standing basins
monobloc installation
metal lever
28 mm ceramic cartridge
with GROHE SilkMove
adjustable flow rate limiter
with temperature limiter
GROHE LongLife finish
GROHE EcoJoy - less water, perfect flow
maximum flow rate (at 3 bar): 5 l/min
GROHE AquaGuide adjustable mousseur
GROHE FastFixation installation system
smooth body
flexible connection hoses
professional edition
Style
Cosmopolitan
Installation Type
Deck mounted
Height (mm)
80.0
Length (mm)
465.0
Width (mm)
235.0
Net Weight (kg)
1.95
Gross Weight (kg)
1.95
Colors & Finishes
Chrome
Collection
Eurosmart 2021
Segment
G3
Features & Technologies
GROHE EcoJoy
GROHE SilkMove
AquaGuide
Extra High Spout (Bathroom)
